GB/T 9CrSi Cold Worked Mold Steel

The usage is:
1. Industrial cutting tools: 9CrSi is often used in the production of industrial cutting tools, such as slitting knives, guillotine blades, and paper cutting blades. Its high hardness and wear resistance make it ideal for cutting materials such as paper, plastic, rubber, and metal.
2. Woodworking tools: 9CrSi is also commonly used in the manufacturing of woodworking tools, such as chisels, planes, and saw blades. Its toughness and edge retention make it suitable for cutting and shaping wood, as well as other materials used in woodworking.
3. Metalworking tools: 9CrSi is used in the production of metalworking tools, such as punches, dies, and shearing blades. Its high hardness and wear resistance make it ideal for cutting and shaping metal, as well as other materials used in metalworking.

  • HONGXIN
  • DAYE
  • 30 DAYS
  • 8000 TON/MONTH
  • Information
Product Description

GB/T 9CrSi Cold Worked Mold Steel9crsi

1: GB/T 9CrSi steel introduction

9SiCr steel is a low-alloy cutting tool steel, but it is also often made of cold work mold parts, and the effect is very good. It has higher hardenability and hardenability than chromium steel (Cr2 or 9Cr2) and has higher tempering stability. Suitable for fractional quenching or isothermal quenching. This steel was first introduced from the former Soviet Union 9XC, used to be called 9CrSi steel. The composition and performance are exactly the same as 9XC. It has a long history of application in our country. The only similar foreign steel numbers are Germany's 90CrSi5, Sweden's 2092 and SR1855, DF-1. Similar steel numbers are not seen in other countries. The steel can be used for a variety of cold working die parts with complex shapes and small deformation requirements.

2: GB/T 9CrSi steel chemical composition

GradeCMnPSSiCrNiCu
9CrSi0.850.950.300.600.030.031.201.600.951.25≤0.25
≤0.30

   3: GB/T 9CrSi steel mechanical properties

9CrSi steel mechanical properties hardness: annealing, 241 ~ 197HB, indentation diameter 3.9 ~ 4.3mm; 187 ~ 229HB (for thread tools); quenching, ≥ 62HRC



  4: GB/T 9CrSi  steel overviews



SizeRoundDia 12-500mm
Plate/Flat/BlockThickness
8mm~300mm

Width
210mm-710mm

ProcessEAF+LF+VD+Forged+Heat treatment(optional)
Heat treatmentNormalized ; Annealed ; Quenched ; Tempered
Surface conditionBlack; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery conditionForged; Hot rolled; Cold drawn
TestTensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment termsT/T;L/C;/Money gram/ Paypal
Trade termsFOB; CIF; C&F; etc..
PackingStandard Packages, or as Customers Request
Delivery time30-45 days


  5: Heat Treatment

Quenching: First, the 9CrSi is heated to 820 ~ 860℃, held for 2 hours, and then quickly cooled by oil cooling. The purpose of this step is to improve the hardness and wear resistance of the material.

Tempering: After quenching, the workpiece is heated to 180 ~ 200℃ for tempering to eliminate the internal stress and brittleness generated during the quenching process, while stabilizing the size of the workpiece and improving toughness.

   6: Delivery condition
    For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
    For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.

    For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.

 9crsi material

9crsi steel

Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range  flats 8-80*210-710mm, rounds 16-50mm Dia.

12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.

8 sets of EF+LF+VD

5 sets of ESR

9 sets of Milling Machines

10 sets of Turning Lathes

sets of Precision Milling Machines.

9crsi material

9crsi steel

9crsi

CERTIFICATION: GB/T19001-2016/ISO9001:20159crsi material

Products' List9crsi steel

Packaging&Shipping

9crsi



9crsi steel



Q1:Are you trading company or manufacturer ?
We are the biggest tool steel factory at Daye &Huangshi. We can provide a wide range of steel products.

Q2:What is alloy steel round bar export packing?

Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.

Q3.What is your MOQ?

We accept small order,if it is stock,any quantities can be accepted.

Q4.What is your lead time?

Depends actual order,around 20-35 days,or negotiation.

Q5.Can you supply sample?

Yes,we can.Sample fee according to your size.

 Q6:What certificates do you have?

ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate

Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.
