DIN 1.2510 Cold Work Mold Steel

DIN 1.2510 is a versatile tool steel grade that is suitable for a wide range of applications in industries such as automotive, aerospace, manufacturing, and construction. Its excellent combination of hardness, toughness, and wear resistance make it a popular choice for demanding applications where durability and performance are essential.

  • HONGXIN
  • DAYE
  • 30 DAYS
  • 8000 TON/MONTH
  • Information
Product Description

DIN 1.2510 Cold Work Mold Steel

1.2510 material



1: DIN 1.2510 steel introduction
DIN 1.2510  tool steel is a low alloy cold work tool steel that must be oil-quenched in heat treatment. Tools and dies made from DIN 1.2510  tool steel flat or rounds will have good wearing and abrasive qualities since the tungsten and higher chromium content gives improved wear resistance.DIN 1.2510  tool steel has deep hardening properties with fine grain structure with unusual toughness. DIN 1.2510  tool steel offers good durability, gives excellent wear resistance and holds a good cutting edge. DIN 1.2510  cold work tool steels also has good response to heat treatment with small dimensional changes.

2: DIN 1.2510  Steel equivalent

CountryGermanyUSAJapanChina
StandardEN ISO 4957ASTM A681JIS 4404GB/T 1299
Grade100MnCrW4/1.2510O1SKS39CrWMn


3: DIN 1.2510 steel chemical composition

GradeCSiMnPSCrVMoW
O10.85-1.00.1-0.51.0-1.40.030.030.4-0.70.3/0.4-0.6
1.25100.9-1.050.15-0.351.0-1.20.030.030.5-0.70.05-0.15/0.5-0.7
SKS30.9-1.00.350.9-1.20.030.030.5-1.0//0.5-1.0


4:DIN 1.2510  steel mechanical properties
  The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.

5: DIN 1.2510  steel overviews

SizeRoundDia 8-350mm
Plate/Flat/BlockThickness
2mm-300mm
Width
200mm-800mm
Heat treatmentNormalized ; Annealed ; Quenched ; Tempered
Surface conditionBlack; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery conditionForged; Hot rolled; Cold drawn
TestTensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment termsT/T;L/C;/Money gram/ Paypal
Trade termsFOB; CIF; C&F; etc..
Delivery time30-45 days
ApplicationO1 used for blanking, forming, and trim dies, gages, slitting cutters, punches, bolster dies, knock-out pins, thread roll dies, bending dies, plastic mold dies, shims, cams, machine ways, stamps, machine parts, jigs, cutter templates, swaging dies, etc.


6: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed, Black surface.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.

1.2510 steel



1.2510 material

Hongxin Mold Tech Co.,Ltd. owns set of Hot Rolling Production Line at size range  flats 8-80*210-710mm, rounds 16-50mm Dia.

12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.

sets of EF+LF+VD

sets of ESR

sets of Milling Machines

10 sets of Turning Lathes

6 sets of Precision Milling Machines.

1.2510 steel

1.2510

1.2510 material

 CERTIFICATION: GB/T19001-2016/ISO9001:20151.2510 steel

Products' List

1.2510

Packaging&Shipping

1.2510 material

 1.2510 material

Q1: Are you trading company or manufacturer ?
We are the largest tool steel manufacturer in Daye & Huangshi. We can provide a wide range of steel products.
Q2: What is alloy steel round bar export packing?
Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.
Q3: What is your MOQ?
We accept small order,if it is stock,any quantities can be accepted.
Q4: What is your lead time?
Depends actual order,around 20-35 days,or negotiation.
Q5: Can you supply sample?
Yes,we can.Sample fee according to your size.
Q6: What certificates do you have?
ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate
Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.
