DIN 1.2360 (X48CRMOV8-1-1) Cold Worked Mold Steel
DIN 1.2360 is a tool steel that is commonly used in the manufacturing industry for various applications. Its high wear resistance, toughness, and good polishability make it ideal for tools and components that require high levels of durability and precision. Some common uses of DIN 1.2360 include:
1. Cutting tools: DIN 1.2360 is often used to make cutting tools such as knives, blades, and shears due to its excellent wear resistance and edge retention properties.
2. Injection molding components: The high toughness and polishability of DIN 1.2360 make it suitable for use in injection molding components such as molds and dies.
3. Cold work tooling: DIN 1.2360 is commonly used in cold work tooling applications where high levels of wear resistance and hardness are required.
4. Industrial equipment: DIN 1.2360 can also be used to make various industrial equipment components such as punches, chisels, and machine parts.
- HONGXIN
- DAYE
- 30 DAYS
- 8000 TON/MONTH
- Information
Product Description
DIN 1.2360 (X48CRMOV8-1-1) Cold Worked Mold Steel
| 1: DIN 1.2360 (X48CRMOV8-1-1) steel introduction Alloy tool steel with increased chromium content, average strength, high hardness, ductility and high abrasion resistance. Used for precision woodworking tools - knives, blades, cutters, handles for the paper, wood, pulp, and paper industries, as well as cold forming tools. The increased content of vanadium provides a high hardenability, which makes it possible to achieve hardness within the limits of 60 HRC.
|
3: DIN 1.2360 (X48CRMOV8-1-1) steel chemical composition
| Standard | Steel Grade | |||||||
|---|---|---|---|---|---|---|---|---|
| Chemical composition % | ||||||||
| C: | Mn: | Si: | P: | S: | Cr: | Mo: | V: | |
| DIN | 1.2360 - X48CrMoV8-1-1 - X 48 CrMoV 8-1-1 | |||||||
| 0.45 - 0.50 | 0.35 - 0.45 | 0.7 - 0.9 | <0.020 | <0.005 | 7.3 - 7.8 | 1.3 - 1.5 | 1.3 - 1.5 | |
4: DIN 1.2360 (X48CRMOV8-1-1) steel mechanical properties and heat treatment
Hardness in annealed condition <240 HB
Annealing in temperatures 835 - 865℃ cooling with furnace
Stress relief annealing at 650℃ cooling the furnace
Quenching at 1035 - 1070℃ with cooling in oil, salt bath or air
Tempering at temperatures 100 - 600℃
| Size | Round | Dia 12-500mm | |
| Plate/Flat/Block | Thickness 8mm~300mm | ||
| Width 210mm-710mm | |||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | ||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | ||
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | ||
| Delivery condition | Forged; Hot rolled; Cold drawn | ||
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | ||
| Payment terms | T/T;L/C;/Money gram/ Paypal | ||
| Trade terms | FOB; CIF; C&F; etc.. | ||
| Packing | Standard Packages, or as Customers Request | ||
| Delivery time | 30-45 days | ||
7:Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range flats 8-80*210-710mm, rounds 16-50mm Dia.
12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.
8 sets of EF+LF+VD
5 sets of ESR
9 sets of Milling Machines
10 sets of Turning Lathes
6 sets of Precision Milling Machines.
CERTIFICATION: GB/T19001-2016/ISO9001:2015
Products' List
Q1:Are you trading company or manufacturer ?
We are the biggest tool steel factory at Daye &Huangshi. We can provide a wide range of steel products.
Q2:What is alloy steel round bar export packing?
Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.
Q3.What is your MOQ?
We accept small order,if it is stock,any quantities can be accepted.
Q4.What is your lead time?
Depends actual order,around 20-35 days,or negotiation.
Q5.Can you supply sample?
Yes,we can.Sample fee according to your size.
Q6:What certificates do you have?
ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate
Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.
