DIN 1.1525 Free Cutting Steel
The usage is:
1. Drill bits: DIN 1.1525 is often used to manufacture drill bits for drilling holes in metal, wood, and other materials. Its high hardness and wear resistance ensure long-lasting performance and efficient cutting.
2. Taps and dies: High-speed steel with DIN 1.1525 specification is also commonly used to make taps and dies for threading operations. Its toughness and heat resistance make it suitable for cutting threads in various materials.
3. Milling cutters: DIN 1.1525 high-speed steel is used to produce milling cutters for shaping and profiling metal workpieces. Its sharp cutting edges and wear resistance allow for precise and efficient machining operations.
- HONGXIN
- DAYE
- 30 DAYS
- 8000 TON/MONTH
- Information
DIN 1.1525 Free Cutting Steel
| 1: DIN 1.1525 steel introduction Tool steels are high quality steels developed with controlled chemical composition to form properties essential for working and shaping of other materials. They are normally delivered to the suppliers in the soft annealed condition, which makes it easy for the manufacturer to machine the material with cutting tool for different applications.AISI T8 tool steel is a tungsten-cobalt-vanadium high-speed tool steel. The following datasheet will provide an overview of grade T8 tool steels. 2: DIN 1.1525 steel chemical composition |
| Element | Content (%) |
|---|---|
| Tungsten, W | 13.25-14.75 |
| Cobalt, Co | 4.25-5.75 |
| Chromium, Cr | 3.75-4.5 |
| Vanadium, V | 1.80-2.40 |
| Carbon, C | 0.75-0.85 |
| Molybdenum, Mo | 0.4-1 |
| Nickel, Ni | 0.3 |
| Copper, Cu | 0.25 |
| Manganese, Mn | 0.2-0.4 |
| Silicon, Si | 0.2-0.4 |
| Phosphorus, P | 0.03 |
| Sulfur, S | 0.03 |
| ReH | Minimum yield strength / Mindestwert der oberen Streckgrenze / Limite d elasticite minimale |
| Rm | Tensile strength / Zugfestigkeit / Resistance a la traction |
| A | Minimum elongation / Mindestwert der Bruchdehnung / Allongement minimal |
| J | Notch impact test / Kerbschlagbiegeversuch / Essai de flexion par choc |
4: DIN 1.1525 steel overviews
| Size | Round | Dia 12-500mm | |
| Plate/Flat/Block | Thickness 8mm~300mm | ||
| Width 210mm-710mm | |||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | ||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | ||
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | ||
| Delivery condition | Forged; Hot rolled; Cold drawn | ||
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | ||
| Payment terms | T/T;L/C;/Money gram/ Paypal | ||
| Trade terms | FOB; CIF; C&F; etc.. | ||
| Packing | Standard Packages, or as Customers Request | ||
| Delivery time | 30-45 days | ||
5: Heat Treatment
Annealing: Annealing temperature/℃: 750~790; After the annealing, degree of hardness ≤HBS: 225
Quenching: Hardening temperature/℃: 1277, Quenching in oil or air
Tempering: Commonly used drawing temperature/℃:552; After tempering hardness HRC : 63 HRc Min
Normalizing：at Normalizing temperature, then cool in furnace
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range flats 8-80*210-710mm, rounds 16-50mm Dia.
12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.
8 sets of EF+LF+VD
5 sets of ESR
9 sets of Milling Machines
10 sets of Turning Lathes
6 sets of Precision Milling Machines.
CERTIFICATION: GB/T19001-2016/ISO9001:2015
Products' List
Q1:Are you trading company or manufacturer ?
We are the biggest tool steel factory at Daye &Huangshi. We can provide a wide range of steel products.
Q2:What is alloy steel round bar export packing?
Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.
Q3.What is your MOQ?
We accept small order,if it is stock,any quantities can be accepted.
Q4.What is your lead time?
Depends actual order,around 20-35 days,or negotiation.
Q5.Can you supply sample?
Yes,we can.Sample fee according to your size.
Q6:What certificates do you have?
ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate
Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.
