DIN 1.2085 Plastic Mold Steel
The utility of plastic mold steel lies in its ability to provide a durable, high-performance material for the production of plastic molds that can withstand the demands of high-volume manufacturing processes.
We owns a whole set of inspection equipments to take control of steel quality.
- HONGXIN
- DAYE
- 30 DAYS
- 8000 TON/MONTH
- Information
1.2085 Plastic Mould Steel
Standard BS EN ISO 4957-2018 Tool Steel.pdf
1: DIN 1.2085 steel introduction
1.2085 Steel displays the best corrosion resistance in hardened condition with a surface polished to give a mirror finisih. Properties: Magnetizable steelm good mechanical resistance and toughness, excellent for manufacturing of components that have to resist to aggressive plastics, good tool machinability thanks to its sulphur content, suitable for working in wet atmosphere and moisture, suitable for polishing, wear and corrosion proof, and very stable dimensionally during heat treatment.
2: DIN 1.2085 Steel equivalent
| Country | China | Japan | Germany | USA | UK |
| Standard | GB/T 1299 | JIS G4404 | DIN EN ISO4957 | ASTM A681 | BS 4659 |
| Grade | 3Cr17+S | SUS420F | 1.2085 | / | / |
3: DIN 1.2085 steel chemical composition
| Grade | C | Si | Mn | P | S | Cr | Mo | Ni |
| SUS420F | 0.26 - 0.4 | ≤1.00 | Max 1.25 | Max 0.06 | Max 0.15 | 12.0~14.0 | Max 0.6 | Max 0.6 |
| 1.2085 | 0.28-0.38 | ≤1.00 | Max 1.40 | Max 0.03 | Max 0.03 | 15.0~17.0 | / | Max 1.0 |
4: DIN 1.2085 steel mechanical properties
The mechanical properties mainly include tensile strength, yield strength, elongation, area or reduction, hardness, impact value, non-metalic inclusion etc. Different heat treatment, the mechanical properties will be different, such as normalized, tempered, QT. If you want to know the properties, kindly contact the salesman.
5: DIN 1.2085 steel overviews
| Size | Round | Dia 12-500mm |
| Plate/Flat/Block | Thickness 8mm-300mm | |
| Width 210mm-710mm | ||
| Process | EAF+LF+VD+Forged+Heat treatment(optional) | |
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Delivery time | 30-45 days | |
6: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed/QT rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed/QT, Black surface.
For hot forged plate, usually the delivery condition is hot forged, annealed/QT, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed/QT, black surface.
Hongxin Mold Tech Co., Ltd. has the capacity to roll and forge round steel, steel flat, square steel, module, shaft and roller, etc. The main specifications of the products include 12-50mm rolling bars, 8~80x310~710mm rolling flats, 50~500 forging round bars, and 80~300x210~710 mm forged flats and which the maximum piece weight can reach 50T.
Company Main Products:(If you do not find the product you need, please contact us)
Cold Work Tool Steel | DIN 1.2080,DIN 1.2379,DIN 1.2436,DIN 1.2210,JIS SKS3,AISI O2 |
Hot Work Tool Steel | H13,DIN 1.2714,DIN 1.2767,DIN 1.2344(H13),DIN 1.2713 |
Engineering Steel | AISI 1020,AISI 1045,AISI1050,AISI 5140,AISI 4130,AISI 4140(40CrMo4),AISI 4340, DIN 1.5919,AISI 8620,S235JR,S355JR |
Plastic Mould Steel | P20,P20+S,P20+Ni,DIN 1.2083,DIN 1.2316,DIN 1.2085 |
Spring Steel | AISI 9260,AISI 5160,AISI 6150,65MN,55CrMnA |
Stainless Steel | 316L,201,301,304,316,410,420,430,431,440C,SUS630(DIN1.4542) |
High Speed Steel | DIN 1.3343(M2),DIN 1.3243(M35),DIN 1.3247,DIN 1.326 |
Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range flats 8-80*210-710mm, rounds 16-50mm Dia.
12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.
8 sets of EF+LF+VD
5 sets of ESR
9 sets of Milling Machines
10 sets of Turning Lathes
6 sets of Precision Milling Machines.
CERTIFICATION: GB/T19001-2016/ISO9001:2015
