AISI 420C Stainless Steel

The utility of 420C:
1. Corrosion resistance: 420C stainless steel is resistant to rust and corrosion, making it ideal for use in humid or wet environments.
2. Edge retention: This steel is able to hold a sharp edge for a long time, reducing the need for frequent sharpening.
3. Easy to sharpen: 420C is relatively easy to sharpen, making it a good choice for beginners or those who prefer to maintain their own blades.
4. Affordable: Compared to higher-end steels, 420C is more budget-friendly while still offering good performance.

  • HONGXIN
  • DAYE
  • 30 DAYS
  • 8000 TON/MONTH
  • Information
Product Description

AISI 420C Stainless Steel AISI 420C

1.Steel Grade:AISI 420C | 1.4034 | BS 420S45 | X46Cr13 |

Stainless steel AISI 420C, also known as 1.4034, BS 420S45 or DIN X46Cr13, is a ferromagnetic martensitic steel. The material is characterised by good wear resistance and polishability (high-gloss polishing is possible). Stainless steel AISI 420C has a density of 7.7 kg/dm³ (at 20 °C), a hardness of ≤ 245 HB and a tensile strength of 800 to 1000 N/mm². The material is easy to forge but difficult to machine. It should not be used for welding.

Martensitic stainless steel 1.4034 has good corrosion resistance (PREN value 12.5 to 14.5), which is, however, negatively affected in the soft-annealed or highly tempered state. It is not resistant to seawater and some acids, nor to intercrystalline corrosion. The material is suitable for hot forming and machining. It is rarely used for cold forming and machining, and is not normally used for cold heading. AISI 420C stainless steel is regularly used in industry for the production of cutting tools such as knives. In medical technology, the material is used, for example, for the production of scalpels and surgical instruments.



2.Comparable Standards:

AFNOR Z44C14 / Z38C13M,AISI 420C,ASTM 420,BS 420S45,JIS SUS420,PN 4H13,RVS 420C,UNE F.3405,UNS S42000



3.Chemical Analysis (%):

CMnSiCrNiMoPS
0.43-0.501.001.0012.5-14.5--≤0.03≤0.03



4.Heat treatment

Hot forming (slow cooling in the furnace): 1100-800 °C
Soft annealing (+A) (slow cooling in the furnace or in air): 750-850 °C
Tempering (+ QT 850) - hardening (rapid cooling in air or in oil): 950-1050 °C
Tempering (+ QT 850) - annealing (rapid cooling in air): 650-700 °C
Stress-relieving annealing: 200 °C


5:AISI 420C steel overviews



SizeRoundDia 12-500mm
Plate/Flat/BlockThickness
8mm-300mm

Width
210mm-710mm

ProcessEAF+LF+VD+Forged+Heat treatment(optional)
Heat treatment  Normalized ; Annealed ; Quenched ; Tempered
Surface conditionBlack; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery conditionForged; Hot rolled; Cold drawn
TestTensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment termsT/T;L/C;/Money gram/ Paypal
Trade termsFOB; CIF; C&F; etc..
Packing Standard Packages, or as Customers Request
Delivery time30-45 days

420C material



AISI 420C

Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range  flats 8-80*210-710mm, rounds 16-50mm Dia.

12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.

8 sets of EF+LF+VD

5 sets of ESR

9 sets of Milling Machines

10 sets of Turning Lathes

6 sets of Precision Milling Machines.

420C steel

AISI 420C

420C material

CERTIFICATION: GB/T19001-2016/ISO9001:2015420C steel

Products' ListAISI 420C



Packaging&Shipping

420C material



AISI 420C



Q1:Are you trading company or manufacturer ?
We are the biggest tool steel factory at Daye & Huangshi. We can provide a wide range of steel products.

Q2:What is alloy steel round bar export packing?

Usually bundling for large diameter,small diameter bars in bulk or as customer's demand.

Q3.What is your MOQ?

We accept small order,if it is stock,any quantities can be accepted.

Q4.What is your lead time?

Depends actual order,around 20-35 days,or negotiation.

Q5.Can you supply sample?

Yes,we can.Sample fee according to your size.

 Q6:What certificates do you have?

ISO, ABS, BV, CCS, Dnv, Lr, Gl, Mill Certificate

Q7: How can I get your quotation as soon as possible?
The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement,we will work out a best price soon.
