DIN 1.2767 Hot Worked Tool Steel
Superior Toughness & Impact Resistance
DIN 1.2767’s high nickel content (3.80-4.30%) ensures exceptional toughness, enabling it to withstand heavy impact loads without cracking. This makes it ideal for forging dies and high-pressure stamping tools subjected to cyclic stress.
Excellent Surface Finish & Polishability
The steel’s fine-grained structure allows for high-gloss polishing, critical for plastic molds requiring mirror-like surfaces. Its low distortion during heat treatment further ensures dimensional accuracy in precision tools.
Adaptability to Extreme Conditions
DIN 1.2767 maintains hardness up to 45 HRC at 650°C, outperforming H13 in thermal fatigue resistance. This thermal stability suits applications like aluminum die-casting and high-temperature extrusion tooling
- HONGXIN
- DAYE
- 30DAYS
- 8000TONS/MONTH
- Information
DIN1.2767(45NiCrMo16) Hot Worked Tool Steel
1.DIN 1.2767 Tool Steel Overview
DIN 1.2767 (X45NiCrMo4) is a high-nickel alloy tool steel renowned for its exceptional toughness, wear resistance, and thermal stability. With a composition of 0.40-0.50% carbon, 3.80-4.30% nickel, and 1.20-1.50% chromium, it achieves a hardness of 52-54 HRC after heat treatment. Its uniform microstructure and deep hardenability make it ideal for large-section tools like plastic injection molds, forging dies, and aerospace components. Widely used in automotive, manufacturing, and heavy machinery industries, DIN 1.2767 balances durability with cost-effectiveness, offering extended tool lifespan under high-stress conditions.
| Heat treatment | Annealed ; | |
| Surface condition | Black; Peeled;Machined;etc | |
| Delivery condition | Forged; Hot rolled; | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Delivery time | 45-50 days | |
| Application | 1.2767 is used for the production of shears for cutting steel sheets and sections, stamping dies, hydraulic chisels, cold forging dies, hardened knives, stamps, punches or moulds for the production of plastics. | |
2. DIN 1.2767 Tool Steel Supply Range
| Size | Round | Dia 16-500mm |
| Plate/Flat/Block | Thickness 6mm-500mm | |
| Width 20mm-810mm |
3. DIN 1.2767 Tool Steel Standards &Chemical Composition
| Country | Europe | USA | China | |
| Standard | DIN | ISO | ASTM | GB/T |
| Grade | 1.2767 | 45NiCrMo16 | 6F7 | 5CrNi4Mo |
| Grade | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr | Mo | Ni |
| 1.2767 | 0.4-0.5 | 0.1-0.4 | 0.2-0.5 | 0.03 | 0.03 | 1.2-1.5 | 0.15-0.35 | 3.8-4.3 |
4. DIN 1.2767 Tool Steel Physical & Mechanical Properties
Physical Properties
| Property | Metric Units |
|---|---|
| Density | 7.85 g/cm³ |
| Melting Point | ~1420°C |
| Thermal Expansion (20-100°C) | 11.8×10⁻⁶/°C |
Mechanical Properties
| Property | Metric Units |
|---|---|
| Hardness (Quenched & Tempered) | 52-54 HRC |
| Tensile Strength | 1900-2100 MPa |
| Impact Toughness (Charpy V-notch) | 23-33 J |
Thermal Fatigue Resistance: Outperforms conventional grades in high-temperature cycles
5. DIN 1.2767 Tool Steel Heat Treatment
Annealing: 660-680°C for 6-8 hours, hardness ≤260 HB.
Quenching: Oil or air cool from 830-860°C.
Tempering: 100-600°C for stress relief and hardness adjustment (52-54 HRC). Double tempering recommended for dimensional stability
6. DIN 1.2767 Tool Steel Applications
DIN 1.2767 excels in high-stress and precision tooling:
Plastic Molds: High-gloss injection molds and large-scale plastic components.
Hot/Cold Work Dies: Forging dies, extrusion tools, and heavy-duty stamping dies.
Cutting Tools: Shear blades, punches, and precision machining tools.
Aerospace & Automotive: High-stress components like transmission shafts and engine parts.
Why Choose DIN 1.2767?
30% longer lifespan in cyclic thermal loads compared to H13.
Superior surface polishability for high-gloss applications.
Key Advantages of DIN 1.2767 Steel
Exceptional Toughness: High nickel (Ni) ensures uniform hardness absorption and resistance to cracking under impact.
Versatile Heat Treatment: Adaptabl to air or oil quenching with minimal distortion, ideal for large-section tools.
Economic Efficiency: Combines durability with lower machining costs, suitable for high-volume production.
7. Delivery Condition
For hot forged bar, usually the delivery condition is hot forged, annealed, rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed, Black surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
Hongxin Mold Tech Co.,Ltd. owns 1 set of Hot Rolling Production Line at size range flats 8-80*210-710mm, rounds 16-50mm Dia.
12 sets of Hydraulic Forging Hammers from Power 560kgs to 6000kgs which could cover flats 40-300*210-710mm.
8 sets of EF+LF+VD
5 sets of ESR
9 sets of Milling Machines
10 sets of Turning Lathes
6 sets of Precision Milling Machines.
CERTIFICATION: GB/T19001-2016/ISO9001:2015
